FTLBW9010 yog tsim los rau cov kws tshaj lij uas xav tau kev muaj peev xwm ua kom pom tseeb yam tsis tau khi rau hauv chav tsev X-ray. Qhov no advancedhandheld X-ray tshuabmuab ob npaug rau lub zog ntawm nws cov counterpart, tso cai rau kev nthuav tawm sai dua thiab muaj peev xwm los duab cov duab thicker lossis denser anatomical thaj chaw tau yooj yim. Txawm hais tias nws muaj zog ntxiv, nws tseem tuaj yeem nqa tau yooj yim ntawm tsuas yog 3.8 kg.
Nrog kV ntau ntawm 40-90 kV thiab mA ntau ntawm 1-10 mA, nws muab kev nkag tau zoo dua thiab cov duab zoo. Lub kaw lus txhawb nqa lub sij hawm raug los ntawm 0.1 mus rau 2 vib nas this thiab yog tsim los nrog lub tshuab ua kom txias uas ua haujlwm rau caum lub sij hawm raug, ua kom nrawm nrawm nrawm thaum xav tau. Zoo li AKBW905, nws suav nrog 0.8 focal chaw, 1.8mm Al pom, thiab roj teeb ua haujlwm kom ua tiav kev txav mus los.
Cov yam ntxwv tseem ceeb:
High Power Output:900W system kom nrawm dua, pom meej dua ntawm kev sib tw anatomies.
Ua kom txias txias:Txhawb kev ua haujlwm siab dua nrog lub sijhawm txias ntawm rau caum npaug ntawm lub sijhawm raug.
Professional Portability:Tsuas yog 3.8 kg, muab lub zog tsis muaj kev cuam tshuam kev txav mus los.
Kev siv ntau yam:Haum rau tib neeg thiab Veterinary radiology thoob plaws ntau daim ntawv thov.
Safety & Clarity:Tsawg hluav taws xob tsim nrog siab - daws teeb meem imaging peev xwm.
Kev sib piv Specifications
| Parameter | wb 905 | FWB 9010 |
|---|---|---|
| Yam khoom qauv | FWB 905 | FWB 9010 |
| Hwj chim | 450W | 900W |
| kV Range | 40-90 kV | 40-90 kV |
| mA Ntau | 0.5-5 mA | 1-10 mA |
| X-Ray Exposure Time | 0.1–2 S | 0.1–2 S |
| Lub sijhawm txias | Peb caug lub sij hawm raug | Rau caum zaus lub sij hawm raug |
| Focal Spot Loj | 0.8 | 0.8 |
| Anode Thaum tshav kub kub muaj peev xwm | 7000J | 7000J |
| Tag nrho cov lim | 1.8mm ua | 1.8mm ua |
| Fais fab mov | Roj teeb | Roj teeb |
| Tej thaj chaw deb Exposure Interface | RJ 11 | RJ 11 |
| Kev ua duab | Xaiv tau | Xaiv tau |
| Ua haujlwm kub | -10℃rau 40 degree | -10℃rau 40 degree |
| Qhov ntev | 225 × 155 × 263 hli | 225 × 155 × 263 hli |
| Qhov hnyav | 3.5 kg ib | 3.8kg ib |
